GENIUS PRO HSC Series CNC Press Brake
WE67K Press Brake Machine

GENIUS PRO HSC Series CNC Press Brake

Name: GENIUS PRO HSC Series CNC Press Brake
Brand: Genuo
SKU: 185184929

The Genius Pro HSC series CNC press brake is based on the validated design of the Genius series. The Y1 and Y2 axis are feedback in real-time through advanced servo proportional valves and Linear encoders, ensuring high bending accuracy and stability. The high-precision back guage system with large stroke and 4-axis can achieve flexible bending dimensions and angles. The machine automatically calculates pressure, protrusion, and unfolding dimensions based on the length and thickness of the workpiece. While continuing the excellent performance of the former, it is equipped with a more powerful CNC controller. The advanced 2D graphics programming function, automatic calculation, and step demonstration combined with the upgraded multi axis back gauge can handle more complex and irregular workpiece bending. Higher configuration machines make machine operation simpler and more efficient. This is a CNC bending machine that integrates precision and high intelligence. 40T~500T and 4~20ft optional.

Send Inquiry

Product Introduction

Standard Equipment	Optional Equipment
◆ Delem DA-66T 7-Axis CNC Control	◇ CYBELEC CybTouch 15, ESA 875W,Delem DA-69T
◆ High-yield steel mono-block frame	◇ Main servo motor SVP control(Energy conservation)
◆ Precision Y1, Y2 axis synchronous Ram positioning	◇ DSP or Keli Lasersafe protection guard
◆ Accurate heavy-duty X,R,Z1,Z2 axis back gauge	◇ CNC sheet follower front support device.
◆ Auto V axis motorized CNC crowning system	◇ Lasercheck angle detection feedback device
◆ European-style punch and 4V/2V/1V Dies	◇ WILA type top and bottom tool clamping system
◆ Fast punch clamps and movable sliding front support	◇ Fully automatic bending robotic cell
◆ SIEMENS main motor,Sunny pump,Schneider Electric	◇ Automatic rail and screw lubrication system
◆ BOSCH Rexroth hydraulic system,GIVI linear encoder	◇ Bending tools management cabinet or trolley
◆ EMB ferrule type pipe connector, NOK sealing rings	◇ Single/Tandem/Trio optional

CNC Controller

Delem DA-66T CNC Controller

.jpg

ESA VIS-875W CNC Controller

⊙Delem DA-66T

⊙ CYBELEC VisiTouch 15

⊙ESA VIS-875W

3D and 2D graphical touch screen prog ramming

with 17" high resolution colo ur TFT.

Full Windows application suite.

DA-66T is applicable to all synchronized series

bending machines of GENIUS,

ECO-GREEN and GAINT. Up to 8+1 axes control

(Y1-Y2 , X1, X2,R1,R2,Z1,Z2 and Crowning)

CybTouch 15 PS is a 2D numerical control specifically

dedicated for entry to mid-range CNC press brakes

up to 6 axes.

The CybTouch 15 PS features an intuitive touch screen

user interface, offering a high integration of functionalities,

User-friendly, easy to operate, simply powerful

and userfriendly.

Ultra-large 21 "TFT LCD Full HD Multitouch screen
both of all 3D Cad-Cams and of any type of machine

up to the incredible limit of 128 axes.
industrial integrated PC with Windows 10

operating system, high-power Intel i5 3.2 Ghz CPU

with 8 Gb of RAM. own Virtually unlimited bi-board

connectivity and expandability

Structure Details

▼Rigid Frame Construction

▼ 4 Axis Back Gauge (X,R,Z1,Z2)

GENUO have vast experience with R&D and designing

components to very tight tolerances with SOLIDWORKS ,

CAD modelling techniques,and that CAE,ANSYS,

SOLIDWORKS used as the method to analyze the

linear static construction, stressand deformation for

machine frames. So for complicated structures,

highly com-plex loadings and transient modelling.

The foundation of all GENUO press brakes is a solid,

monoblock frame made from high-yield steel.

Establishing the right back gauge for your projects will

allow for increased part production and precision.

From intricate parts which typically require more axes

to large quantities that require more time and therefore

increased cost, the correct back gauge for each job is

essential to lowering costs per part which ultimately

benefts your bottom line. GENUO technicians are

happy to assist you with any questions you may

have on your project requirements.

▼Closed-loop Proportional Control

▼Linear Encoder Feedback

German Bosch Rexroth integrated "hydraulic system

block", hydraulic transmission with high reliability ,

integrated hydraulic system can effectively alleviate

the problem caused by leakage of hydraulic fluid.

The deformation is measured accurately and com-

pensated by feedback method.

The accuracy can be achieved uM level.

Tooling and Clamping

GENUO provides a variety of tooling solutions to meet your different production needs. Not only that, we are also experts in the field of bending tools.

If you have any special bend, our engineers will customize special tools for each workpiece, which greatly expands your press brake function and revenue.

To help greatly improve your productivity and business benefits.
